Table 1 shows the quick spec.
|
Model |
CloudEngine S1730S-H24T4S-A |
|
Forwarding Performance |
41.66 mpps |
|
Switching Capacity |
168 Gbit/s |
|
Fixed Ports |
24 x 10/100/1000Base-T Ethernet ports, 4 x GE SFP ports |
|
Power Supply |
Built-in AC power module |
|
Dimension (H × W × D) |
43.6mm × 442mm × 220mm |
Table 2 shows the recommended modules.
|
Product |
Description |
|
eSFP-GE-SX-MM850 |
Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.55km, LC) |
|
SFP-GE-LX-SM1310 |
Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
|
S-SFP-GE-LH40-SM1310 |
Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC) |
|
S-SFP-GE-LH40-SM1550 |
Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 40km, LC) |
|
S-SFP-GE-LH80-SM1550 |
Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 80km, LC) |
|
eSFP-GE-ZX100-SM1550 |
Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 100km, LC) |
|
SFP-GE-LX-SM1310-BIDI |
Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 10km, LC) |
|
SFP-GE-LX-SM1310-BIDI |
BiDi Transceiver, eSFP, Tx1310nm/Rx1490nm, 1.25Gb/s, -9dBm, -3dBm, -19.5dBm, LC, SM, 10km |
|
SFP-GE-LX-SM1490-BIDI |
Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1310, 10km, LC) |
|
SFP-GE-LX-SM1490-BIDI |
BiDi Transceiver, eSFP, Tx1490nm/Rx1310nm, 1.25Gb/s, -9dBm, -3dBm, -19.5dBm, LC, SM, 10km |
|
CWDM-SFPGE-1471 |
CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1471nm, 80km, LC) |
|
CWDM-SFPGE-1491 |
CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1491nm, 80km, LC) |
|
CWDM-SFPGE-1511 |
CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1511nm, 80km, LC) |
|
DWDM-SFPGE-1560-61 |
DWDM Optical Transceiver.eSFP.2.5G.Single-mode Module (1560.61nm.120km.LC) |
|
SFP-1000BaseT |
1000BASE-T (RJ45) SFP Electrical Module, Auto Negotiate, 100m |
Table 3 shows the comparison.
|
Parameters |
CloudEngine S1730S-H24T4S-A |
CloudEngine S1730S-H48T4S-A |
|
Forwarding Performance |
41.66 mpps |
77.38 mpps |
|
Switching Capacity |
168 Gbit/s |
216 Gbit/s |
|
Fixed Ports |
24 x 10/100/1000Base-T Ethernet ports, 4 x GE SFP ports |
48 x 10/100/1000Base-T Ethernet ports, 4 x GE SFP ports |
S1730S-H24T4S-A Specification |
|
|
Forwarding Performance |
41.66 mpps |
|
Switching Capacity |
168 Gbit/s |
|
Fixed Ports |
24 x 10/100/1000Base-T Ethernet ports, 4 x GE SFP ports |
|
Power Supply |
Built-in AC power module |
|
Dimension (H × W × D) |
43.6mm × 442mm × 220mm |
|
Chassis Height |
1U |
|
Rated Voltage Range |
- 100V AC to 240V AC, 50/60 Hz - High-voltage DC input: 240V DC |
|
Maximum Voltage Range |
- 90V AC to 264V AC, 47 Hz to 63 Hz - High-voltage DC input: 190V DC to 290V DC |
|
Maximum Power Consumption |
34W |
|
Operating Temperature |
5°C to +45°C (23°F to 113°F) at an altitude of 0-1800m (0-5906 ft.) |
|
Storage Temperature |
-40°C to +70°C (-40°F to +158°F) |
