Note:
① |
Twenty-four 10/100/1000BASE-T ports |
④ |
One RST button |
② |
Four 1000BASE-X ports |
⑤ |
One console port |
③ |
One ETH management port |
⑥ |
One USB port |
S1730S-H24T4S-A Specification |
|
Forwarding Performance |
41.66 mpps |
Switching Capacity |
168 Gbit/s |
Fixed Ports |
24 x 10/100/1000Base-T Ethernet ports, 4 x GE SFP ports |
Power Supply |
Built-in AC power module |
Dimension (H × W × D) |
43.6mm × 442mm × 220mm |
Chassis Height |
1U |
Rated Voltage Range |
- 100V AC to 240V AC, 50/60 Hz - High-voltage DC input: 240V DC |
Maximum Voltage Range |
- 90V AC to 264V AC, 47 Hz to 63 Hz - High-voltage DC input: 190V DC to 290V DC |
Maximum Power Consumption |
34W |
Operating Temperature |
5°C to +45°C (23°F to 113°F) at an altitude of 0-1800m (0-5906 ft.) |
Storage Temperature |
-40°C to +70°C (-40°F to +158°F) |
