FG-90E is the Fortinet NGFW Entry-level Series FortiGate 90E firewall. The FortiGate 90E offers an excellent network security solution in a compact desktop form factor for enterprise branch offices and mid-sized businesses.
Table 1 shows the quick spec.
SKU |
FG-90E |
Firewall |
4 Gbps |
IPS |
470 Mbps |
NGFW |
375 Mbps |
Threat Protection |
270 Mbps |
Interfaces |
16x GE RJ45 ports (including 2x WAN ports, 1x DMZ port, 1x HA port, 12x switch ports) |
FG-90E Specification |
|
Type |
FORTIGATE 90E |
Hardware Specifications |
|
GE RJ45 Ports |
16 |
USB Ports |
1 |
Console (RJ45) |
1 |
Internal Storage |
- |
System Performance and Capacity |
|
Firewall Throughput |
4 Gbps |
Firewall Latency (64 byte UDP Packets) |
182 μs |
Firewall Throughput (Packet per Second) |
375 Kpps |
Concurrent Sessions (TCP) |
1.2 Million |
New Sessions/Second (TCP) |
27,500 |
Firewall Policies |
5,000 |
IPsec VPN Throughput (512 byte) |
245 Mbps |
Gateway-to-Gateway IPsec VPN Tunnels |
200 |
Client-to-Gateway IPsec VPN Tunnels |
2,500 |
SSL-VPN Throughput |
95 Mbps |
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
200 |
SSL Inspection Throughput (IPS, HTTP) |
300 Mbps |
Application Control Throughput |
510 Mbps |
CAPWAP Throughput (HTTP 64K) |
950 Mbps |
Virtual Domains (Default / Maximum) |
10 / 10 |
Maximum Number of Switches Supported |
8 |
Maximum Number of FortiAPs (Total / Tunnel Mode) |
32 / 16 |
Maximum Number of FortiTokens |
100 |
Maximum Number of Registered FortiClients |
200 |
High Availability Configurations |
Active / Active, Active / Passive, Clustering |
System Performance — Optimal Traffic Mix |
|
IPS Throughput |
1 Gbps |
System Performance |
|
IPS Throughput |
470 Mbps |
NGFW Throughput |
375 Mbps |
Threat Protection Throughput |
270 Mbps |
Dimensions and Power |
|
Height x Width x Length |
1.7 x 8.5 x 7.0 inches 43.9 x 216 x 178.5 mm |
Form Factor |
Desktop |
Power Required |
100–240V AC, 60–50 Hz (External DC Power Adapter) |
Power Consumption (Average / Maximum) |
22.8 W / 27.36 W |
Current (Maximum) |
100V AC / 1.5A |
Heat Dissipation |
77.7936 BTU/h |
Operating Environment and Certifications |
|
Operating Temperature |
32–104°F (0–40°C) |
Storage Temperature |
-31–158°F (-35–70°C) |
Humidity |
10–90% non-condensing |
Noise Level |
40 dB |
Operating Altitude |
Up to 7,400 ft (2,250 m) |
Compliance |
FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB |
Certifications |
ICSA Labs: Firewall, IPSec, IPS, Antivirus, SSL VPN; USGv6/IPv6 |
